R7J39A HPE 2.4GBPS 802.11ax Tri Band Wireless Access Point

The HPE Aruba R7J39A is a high-performance enterprise-grade wireless access point designed to deliver ultra-fast and reliable connectivity for today’s demanding networks. Equipped with the latest Wi-Fi 6 (802.11ax) technology and tri-band architecture, it supports high-density environments such as offices, campuses, healthcare facilities, and retail spaces.

Offering a combined data rate of up to 2.4 Gbps, the R7J39A enhances overall network performance, reduces latency, and provides secure connectivity for a wide range of devices. With support for AI-powered management, advanced security, and flexible deployment options, it ensures seamless scalability and efficient operation for modern enterprise networks.

Key Features

• Wi-Fi 6 (802.11ax) Technology: Delivers higher speeds, greater capacity, and improved performance for multi-device environments.

• Tri-Band Design: Provides enhanced efficiency and reduced interference for high-density user areas.

• High Data Rate: Supports combined wireless throughput of up to 2.4 Gbps.

• Advanced Security: Features WPA3 encryption, secure boot, and integrated firewall policies.

• AI-Powered Optimization: Works with Aruba Central or AirWave for real-time analytics and performance tuning.

• Flexible Deployment: Operates in controller-based or Instant (controllerless) mode for easy deployment.

• IoT-Ready: Integrated Bluetooth Low Energy (BLE) and Zigbee radios for IoT device support.

• Energy Efficient: Compatible with 802.3at Power over Ethernet (PoE+) for simplified cabling and reduced operational costs.

Technical Specifications

General:

• Model: HPE Aruba R7J39A

• Type: Enterprise-grade indoor access point

Wireless Standards:

• IEEE 802.11 a/b/g/n/ac/ax (Wi-Fi 6)

• Tri-band operation: 2.4 GHz, 5 GHz, and a dedicated 5 GHz or 6 GHz band (model dependent)

Performance:

• Maximum Data Rate: Up to 2.4 Gbps (aggregate)

• MIMO Support: 2×2:2 or higher depending on band

• OFDMA and MU-MIMO for optimized multi-user performance

• Target Wake Time (TWT) for improved client device battery life

Security:

• WPA2 and WPA3 Enterprise/Personal

• Integrated TPM for hardware-level security

• Secure boot and role-based access control

Interfaces:

• 1x 10/100/1000/2500BASE-T Ethernet port with PoE+ (802.3at)

• Bluetooth 5.0 and Zigbee radios for IoT connectivity

Power & Environmental:

• Power Source: 802.3at PoE+ or DC power (adapter sold separately)

• Typical Power Consumption: Up to 16 W (with PoE+)

• Operating Temperature: 0°C to 40°C (32°F to 104°F)

Management & Control:

• Supported Platforms: Aruba Central (cloud), Aruba AirWave (on-premise), or local controller

• Deployment Modes: Controller-based or Instant

Physical:

• Mounting: Ceiling or wall mount

• Dimensions: (Varies by model, typically ~160 mm x 160 mm x 40 mm)

• Weight: Approx. 0.6 kg
